Description
Match the required roller weight and working width to the flooring installation specification.
Full-area rolling after flooring installation
Choose the nominal 30, 50 or 80kg roller around the adhesive and flooring manufacturer’s rolling requirement. Compare handling, contact width and site access alongside nominal mass.
| What matters on site | Practical value |
|---|---|
| Apply the specified rolling method | Follow the flooring system’s rolling pattern and timing. A heavier roller is not automatically the correct choice for every floor. |
| Check segmented contact | Inspect the roller segments and the floor so debris does not mark the surface. |
| Plan movement between rooms | Check turning space, transport wheels, handle connection and safe loading arrangements for the selected mass. |
Apply the specified rolling method
Follow the flooring system’s rolling pattern and timing. A heavier roller is not automatically the correct choice for every floor.
Check segmented contact
Inspect the roller segments and the floor so debris does not mark the surface.
Plan movement between rooms
Check turning space, transport wheels, handle connection and safe loading arrangements for the selected mass.
Key specifications and configuration
| Item | Specification |
|---|---|
| Listed assembled dimensions (mm) | 385 × 260 × 1125 |
| Nominal roller mass (kg) | 30 |
| Effective rolling width (mm) | 380 |
| Handle material | Q235 steel |
| Connection | Quick-release clamp |
| Net weight (kg) | 31.5 |
| Handle diameter (mm) | 32 |
Listed assembled dimensions (mm):
385 × 260 × 1125
Nominal roller mass (kg):
30
Effective rolling width (mm):
380
Handle material:
Q235 steel
Connection:
Quick-release clamp
Net weight (kg):
31.5
Handle diameter (mm):
32
Compare the options
30kg vs. 50kg vs. 80kg Floor Rollers
| Configuration | Dimensions and construction |
|---|---|
| 30kg | Nominal Weight: 30kg, approximately 66lb Recorded Net Weight and Included Components: 31.5kg; separate base/handle recorded, weighing scope requires recheck. Contact and Transport Structure: Three roller sections; effective rolling width 380mm. Chrome-plated Grade 45 steel, quick-release handle, two transport wheels; roller diameter remains unrecorded. |
| 50kg | Nominal Weight: 50kg, approximately 110lb Recorded Net Weight and Included Components: 51.93kg; separate base/handle recorded, weighing scope requires recheck. Contact and Transport Structure: Four roller sections; effective rolling width 515mm. Chrome-plated Grade 45 steel, quick-release handle, two transport wheels; roller diameter remains unrecorded. |
| 80kg | Nominal Weight: 80kg, approximately 176lb Recorded Net Weight and Included Components: 80kg; measured roller-only weight, complete tool must be weighed separately. Contact and Transport Structure: Four roller sections, Φ157mm; individual-section widths 110/130mm; recorded effective rolling width 515mm. Verify supplied arrangement; transport-wheel and quick-release details remain unconfirmed. |
| Configuration | Application and value | Selection checks |
|---|---|---|
| 30kg | Installation permits 30kg and reduced frequent-move handling load is desired. Lower weight option; unsuitable for projects requiring a heavier roller. | |
| 50kg | Requirements specify or permit 50kg and the site can handle the weight. Intermediate weight option; increases control and handling load and must meet requirements. | |
| 80kg | Requirements specify or permit 80kg and operating/loading conditions are suitable. Higher weight option; does not establish better bonding or suit every system. |
30kg
Dimensions and construction:
Nominal Weight: 30kg, approximately 66lb
Recorded Net Weight and Included Components: 31.5kg; separate base/handle recorded, weighing scope requires recheck.
Contact and Transport Structure: Three roller sections; effective rolling width 380mm. Chrome-plated Grade 45 steel, quick-release handle, two transport wheels; roller diameter remains unrecorded.
Application and value:
Installation permits 30kg and reduced frequent-move handling load is desired. Lower weight option; unsuitable for projects requiring a heavier roller.
50kg
Dimensions and construction:
Nominal Weight: 50kg, approximately 110lb
Recorded Net Weight and Included Components: 51.93kg; separate base/handle recorded, weighing scope requires recheck.
Contact and Transport Structure: Four roller sections; effective rolling width 515mm. Chrome-plated Grade 45 steel, quick-release handle, two transport wheels; roller diameter remains unrecorded.
Application and value:
Requirements specify or permit 50kg and the site can handle the weight. Intermediate weight option; increases control and handling load and must meet requirements.
80kg
Dimensions and construction:
Nominal Weight: 80kg, approximately 176lb
Recorded Net Weight and Included Components: 80kg; measured roller-only weight, complete tool must be weighed separately.
Contact and Transport Structure: Four roller sections, Φ157mm; individual-section widths 110/130mm; recorded effective rolling width 515mm. Verify supplied arrangement; transport-wheel and quick-release details remain unconfirmed.
Application and value:
Requirements specify or permit 80kg and operating/loading conditions are suitable. Higher weight option; does not establish better bonding or suit every system.
Selection and use
| Step | What to check |
|---|---|
| Check the flooring instructions | Confirm required nominal roller mass, rolling direction and timing. |
| Inspect and assemble | Check segment cleanliness, rotation and the removable handle connection. |
| Roll and inspect | Follow the specified pattern and check the installed floor. Plan loading separately from normal rolling. |
Check the flooring instructions:
Confirm required nominal roller mass, rolling direction and timing.
Inspect and assemble:
Check segment cleanliness, rotation and the removable handle connection.
Roll and inspect:
Follow the specified pattern and check the installed floor. Plan loading separately from normal rolling.
Logo customization
The image shows the identified customization area for this product. Send the artwork and required quantity so the placement, marking method and final proof can be confirmed before production.
Frequently asked questions
Is 30kg Suitable for Every Small Room?
Area is not the only criterion. If flooring or adhesive requires a heavier roller, do not reduce the weight option merely because the room is small.
What Is the Difference Between 30kg and 31.5kg?
30kg is the nominal weight class; 31.5kg is the local net-weight record, with included components requiring confirmation.
Do the Transport Wheels Help on Stairs?
They are for movement on level surfaces. Lifting, stairs, and vehicle loading still require handling the tool's weight.
Can It Replace a Hand Pressure Roller?
Large and small rollers differ in contact coverage and access. Select each according to installation requirements.
Does a Heavier Roller Produce a Stronger Bond?
Weight alone is insufficient; adhesive transfer, open time, subfloor, and flooring system jointly affect results.
